Dust Test Chamber – DST
Technical Data Sheet
• Temperature Range: 5℃ above ambient to + 80℃ ±1℃
• Performance: Conform IS 9000, JSS 55555, IS 12063 / IEC 60529 (IP), JIS D 0207 (C & F)
• ISO 9000/ JSS 55555 Dust agitator mechanism as per IS 9000 / JSS 55555 designed to give 25 grams ±5 grams in 5 minutes. Dust measuring device conforming to JSS 55555.
• ISO 12063/ IEC 60529 (IP) Dust dispersing and suspension arrangement using blower and motor. Vacuum pump with vacuum valve, dust filter, Pressure gauge & Rotameter with manometer tube to fulfil specifications.
• JIS D 0207 Circulating dust test 'C' High pressure blower to generate velocities of 5m/s and 10m/s.
• Floating Dust Test (F) Dust suspension using pneumatic nozzles with timer.
Standard Test Space :
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
| DST - 90 | 420 | 750 | 750 | 750 |
| DST - 200 | 1000 | 1000 | 1000 | 1000 |
