Description
Features
✓ Dual loop Microprocessor programmer, Touchscreen based HMI with ethernet
facility.
✓ Unlimited real time recording of temperature measured values versus time (log
on Pen Drive).
✓ Recordings in CSV format (Comma Separated Value) for easy export to Excel® to
Pendrive via USB interface placed on the front panel.
✓ Cycles as per requirement can be programmed directly from the touchscreen.
✓ Remote Monitoring through PC on Ethernet with VNC. VNC will be free download
version.
✓ Air cooled / Water cooled Semi Hermetic type. CFC free refrigeration system
Performance Conform IS 9000, DEF-STD-133, IEC 68 Specifications
✓ PID type controllers OR Microprocessor programmer, Touchscreen based control
system with ethernet facility, Recorder. Air cooled / Water cooled / Semi
Hermetic type CFC free refrigeration system.
✓ Transfer Time: <10 Sec.
✓ Performance: Conform IS 9000, JSS 55555, 50101, IEC 68, MIL- STD-202, 810, 883,
DEF-STD-133 Specifications.
Standard Test Space:
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
| TSC – 27 | 27 | 300 | 300 | 300 |
| TSC – 90 | 90 | 450 | 450 | 450 |
| TSC – 200 | 200 | 600 | 600 | 600 |
• Test Space can be provided as per customer requirement
• Appearance & Design of Chamber may vary depending on the internal dimension
• All performance measured at Room temperature / Ambient of ±25℃ to ±2℃
